Rapid Additive Manufacturing of Microelectronics

Accelerating innovation through additive processes and service-led development

VISION

We’re Here to Revolutionize Semiconductor Fabrication

Nano OPS was founded on a simple belief: microelectronics manufacturing should be faster, more flexible, and more accessible. Today’s subtractive, multi-step fabrication methods limit design freedom and slow iteration. Our vision is a future in which custom architectures can be designed, validated, and produced with greater speed and precision—without the cost or constraints of traditional fabrication.

By pairing chip prototyping expertise with our patented additive process, we provide a direct path from concept to scalable production. Teams gain the confidence to innovate, refine designs in days rather than months, and build advanced systems ready for real-world manufacturing.

FAB IN A BOX

Fully Autonomous, Uncompromisingly Sustainable

Rapid Chip Prototyping

Fab in a Box accelerates chip prototyping by enabling design validation and iteration directly on the platform. Engineers can test new device structures quickly, shorten development cycles, and move confidently toward pilot production.


Scalable Additive Manufacturing

Our system transforms how teams approach microelectronics manufacturing, providing a pathway from prototype to production without traditional fabrication constraints. By removing process bottlenecks, Fab in a Box shortens time to deployment while maintaining precision and repeatability.

Advanced Packaging Manufacturing Support

Fab in a Box supports complex integration needs—including advanced packaging manufacturing and heterogeneous structures. This empowers development of next-generation modules with tighter integration, refined architecture, and fewer dependencies on external fabs.


PERFORMANCE

Nano OPS in Numbers

20 nm

Resolution

1000x

Faster

1000x

Higher Resolution

10-100x

Cost Savings


WHY NANO OPS

A Different Approach, Using a New Method of Manufacturing

Nano OPS combines chip prototyping services, additive manufacturing technology, and a fab-ready production platform to create a continuous path from concept to market. Our patented process allows teams to integrate new architectures, customize more freely, and build advanced systems at the wafer scale.

Whether validating new device structures or scaling advanced packaging manufacturing, we provide the tools, expertise, and support needed to move faster with confidence. With Nano OPS, organizations gain a partner committed to precision, speed, and the future of manufacturing.

COMPANY

Our Industry Partners

Explore the Future of Manufacturing
